RSM Motors

Rugged brushless, flexible designed PMAC motor for use in a variety of  applications
pwr-img_icon_product-01svg
Quality and reliability
Superior design and outstanding manufacturing processes. Rugged design suitable for the demanding environment. Protected against ingress of dust and water to IP65
pwr-img_icon_product-03svg
Exact flexibility
The logic platform offers unparalleled flexibility in software customization, as well as adherence to demanding functional safety requirements.
pwr-img_icon_product-02svg
Safety certified

To ensure sustainable functional safety and electrical safety both on-road and off-road, we work according to the latest standards used in the industry.

pwr-img_icon_product-04svg
Cybersecurity

Security and safety are key! We use best-practice cybersecurity management according to established standards, we stay up to date and on our toes!

RSM 800x800-1

The RSM motors

RSM is a family of motors with power levels from 3 to 15 kW for system voltages between 36V and 96V. The RSM is designed with hydraulic pump applications in mind which makes it an ideal choice for most battery-powered or hybrid electric vehicles / equipment

  • Features
  • Spec
  • Models

Features

  • Best-in-class quality and reliability, achieved through superior design and world-class manufacturing processes
  • The rugged design is suitable for the demanding environment of vehicles. Protected against ingress of dust and water
  • Customizable mechanical interface The RSM motors can easily be adapted for different gearboxes, pumps or other mechanical interfaces
  • Sin/Cos position feedback Sin/Cos feedback is included as the standard type of motor position feedback
  • Very high efficiency The PMAC-motor design gives superior efficiency compared to DC, PMDC and induction motors. The RSM motors are specifically designed to give high efficiency over a wide usable speed and torque range, and not only at a single load point

Spec

General

 Min

 Max

Stack Length:

60 mm

240 mm

Rated Torque (S2 2 min)

13 Nm

146 Nm

Power (S2 60min)

4 kW

16 kW



Models

Performance

Model

1000 rpm
Rated torque
(S2 2 min)

1500 rpm
Rated torque
(S2 2 min)

2500 rpm
Rated torque
(S2 2 min)



3500 rpm
Rated torque
(S2 2 min)



Power
(S2 2 min)

RSM 170-60

33 Nm

30 Nm

 18 Nm

13 Nm

5 kW

RSM170-120

64 Nm

60 Nm

34 Nm

25 Nm

7 kW

RSM 170-170

81 Nm

81 Nm

68 Nm

47 Nm

12 kW

RSM 170-200

118  Nm

117   Nm

90  Nm

60 Nm

115 kW

RSM170-240

146  Nm

144 Nm

92  Nm

62 Nm

15 kW
