Heavy Equipment

High-efficiency DC/DC Converters

The DCC2 converters are the ideal choice for most hybrid and electric vehicles with input voltages from 350 V to 650 V and an adjustable secondary voltage.

pwr-img_icon_product-01svg
Quality and reliability
Features a rugged design suitable for the most demanding environments. Protected against the ingress of dust and water to an IP6K9K rating.
pwr-img_icon_product-03svg
Exact flexibility
The logic platform offers unparalleled flexibility in software customization, as well as adherence to demanding functional safety requirements.
pwr-img_icon_product-02svg
Safety certified

To ensure sustainable functional safety and electrical safety both on-road and off-road, we work according to the latest standards used in the industry.
pwr-img_icon_product-04svg
Cybersecurity

Security and safety are key! We use best-practice cybersecurity management according to established standards, we stay up to date and vigilant!
DCC2 cable lug without cover

DCC35M24



THE OPTIMAL FIT FOR ELECTRIC AND HYBRID VEHICLES

Safety is key with the 2nd generation DC/DC converter. we work according to the requirements set forth by the European standards for electrical and functional safety

DCC65M24



THE OPTIMAL FIT TO ALL VEHICLE TYPES

With adjustable output voltage and current output limitation, the DCC65M24 can adapt to different applications with the ability to connect many devices in parallel, achieving higher delivered power at secondary voltages.

DCC2
  • Features
  • Specifications
  • Models

Features

  • High efficiency (up to 95 %) using Silicon Carbide (SiC) technology
  • Adjustable output voltage and current output limitation for best adaptability to different uses
  • Possible to parallel multiple units to achieve higher delivered power at
    secondary voltage
  • Liquid (WEG) cooled
  • Insulation between primary and secondary voltage for personal safety
  • Rugged IP6K9K design suitable for the demanding environment of electric vehicles
  • CAN communication, J1939 and/or CANopen with support for diagnostics and software download

Specifications

General

Communication:

CAN (CANOpen, J1939)

Control mode:

Voltage or current

Shock and Vibration:

ISO16750-3

Electrical safety:

ISO 6469-3

CONNECTIONS

I/O logic connector:

 MCP connector (21 pins)

Low side connection (power out):

Cable lugs (M8 and M10)

High side connection (power in):

Amphenol C91-665343-AFS

TEMPERATURE AND COOLING

Required WEG coolant flow:

 5-18 l/min

Ambient operating temperature:

-40 °C to +85 °C

ELECTRICAL SAFETY AND EMC

Safety feature:

Hazardous Voltage Interlock Loop (HVIL)

EMC:

UN ECE R10





Models

Model

Nominal input Voltage

Nominal output voltage 1

Max output current 2

Output power

Voltage range



DCC35M24



350 V

14.1 V

160 A

1.90 kW



270-450 V

28.3 V

135 A

3.75 kW

DCC65M24

350 V

14.1 V

270 A

3.75 kW

270-750 V

650 V

14.1 V

270 A

3.75 kW

28.3 V

7.50

450-750 V



1 Output voltage is adjustable via CAN or parameter. Typical output voltage for 12/24V battery shown in the table.

2 Continuous ratio
