RSM Motors

Quality and reliability

Superior design and outstanding manufacturing processes. Rugged design suitable for the demanding environment. Protected against ingress of dust and water to IP65

Exact flexibility

The logic platform offers unparalleled flexibility in software customization, as well as adherence to demanding functional safety requirements.

Safety certified

To ensure sustainable functional safety and electrical safety both on-road and off-road, we work according to the latest standards used in the industry.

Cybersecurity

Security and safety are key! We use best-practice cybersecurity management according to established standards, we stay up to date and on our toes!

Features

Best-in-class quality and reliability, achieved through superior design and world-class manufacturing processes
The rugged design is suitable for the demanding environment of vehicles. Protected against ingress of dust and water
Customizable mechanical interface The RSM motors can easily be adapted for different gearboxes, pumps or other mechanical interfaces
Sin/Cos position feedback Sin/Cos feedback is included as the standard type of motor position feedback
Very high efficiency The PMAC-motor design gives superior efficiency compared to DC, PMDC and induction motors. The RSM motors are specifically designed to give high efficiency over a wide usable speed and torque range, and not only at a single load point

Spec

General	Min	Max
Stack Length:	60 mm	240 mm
Rated Torque (S2 2 min)	13 Nm	146 Nm
Power (S2 60min)	4 kW	16 kW

Models

Performance

Model	1000 rpm Rated torque (S2 2 min)	1500 rpm Rated torque (S2 2 min)	2500 rpm Rated torque (S2 2 min)	3500 rpm Rated torque (S2 2 min)	Power (S2 2 min)
RSM 170-60	33 Nm	30 Nm	18 Nm	13 Nm	5 kW
RSM170-120	64 Nm	60 Nm	34 Nm	25 Nm	7 kW
RSM 170-170	81 Nm	81 Nm	68 Nm	47 Nm	12 kW
RSM 170-200	118 Nm	117 Nm	90 Nm	60 Nm	115 kW
RSM170-240	146 Nm	144 Nm	92 Nm	62 Nm	15 kW
