ASM Motors

Quality and reliability

Superior design and outstanding manufacturing processes. Rugged design suitable for the demanding environment. Protected against ingress of dust and water to IP65

Exact flexibility

The logic platform offers unparalleled flexibility in software customization, as well as adherence to demanding functional safety requirements.

Safety certified

To ensure sustainable functional safety and electrical safety both on-road and off-road, we work according to the latest standards used in the industry.

Cybersecurity

Security and safety are key! We use best-practice cybersecurity management according to established standards, we stay up to date and on our toes!

Features

Rugged design, suitable for the demanding environment of vehicles. Protected against ingress of dust and water
Customizable mechanical interface. The ASM motors can easily be adapted for different gearboxes, pumps or other mechanical interfaces
Sin/Cos position feedback is included as the standard type of motor position feedback
Dual Sin/Cos position feedback. For safety-critical applications such as fly-by wire steering the ASM motors have a redundant dual Sin/Cos position feedback option
Small dimensions but high performance make the ASM motors easy to fit in tight spaces
The ASM motors are specifically designed to give high efficiency over a wide usable speed and torque range
Available with a variety of gearboxes

Spec

General	Min	Max
Stack Length:	30 mm	150 mm
Rated Torque (S2 60min)	2.0 Nm	11.0 Nm
Peak Torque CS2 2min)	5.2 Nm	27.3 Nm
Power (S2 60min)	600 W	2 150 W

Models

Performance

Model	500 rpm Rated torque (S2 60 min)	2 200 rpm Rated torque (S2 60 min)	3 000 rpm Rated torque (S2 60 min)	Power (S2 60 min)
ASM 103	2.8 Nm	2.3 Nm	2.0 Nm	630 W
ASM 106	4.8 Nm	4.0 Nm	3.8 Nm	1 200 W
ASM 109	6.8 Nm	6.1 Nm	4.7 Nm	1 475 W
ASM 112	9.2 Nm	7.8 Nm	5.9 Nm	1 850 W
ASM 115	11.0 Nm	8.6 Nm	6.8 Nm	2 150 W

Peak performance

Model	500 rpm Rated torque (S2 2 min)	2 200 rpm Rated torque (S2 2 min)	3 000 rpm Rated torque (S2 2 min)
ASM 103	5.5 Nm	5.3 Nm	5.2 Nm
ASM 106	10.6 Nm	10.6 Nm	10.4 Nm
ASM 109	16.4 Nm	15.9 Nm	15.7 Nm
ASM 112	21.8 Nm	21.2 Nm	20.4 Nm
ASM 115	27.3 Nm	26.4 Nm	21.9 Nm
